SPECIFICATION:
Rating: 3A , 5A 125/250V AC
SIZE: 19.8 x 10.6 x 6.4mm
Operating Force: 13, 18, 23, 28, 30, 35g
Lever: 15.8mm
Terminal: PCB Type
Withatand Voltage: AC 1,000 V 1 Minute
Insulation Resistance: 100 MΩ Mim. 500V DC
Contact Resistance: 50MΩ
Operating Temperature: -25oC ~ +80oC
Mechanical Life: 100,000 Cycles
Electrical Life: 6,000 Cycles
Approvals : RoHS,UL,CSA,VDE,CE,3C
