SPECIFICATION:

Rating: 1A,3A,6A,10A 125/250V AC
Screw on 36 mm

With Fuse Holder

#250 Terminal (6.3mm)

Operating Frequency: 50/60Hz

Hipot Rating: Line to Line: 1450V DC

                    Line to Ground: 2250V DC

Leakage Current: 0.8mA Max

Insulation Resistance: 100MΩ Min 250V DC

Temperature Rise: 30 ℃ Max

Operating Temperature: -25^oC ~ +85^oC

Approvals : RoHS,UL,CSA,VDE,CQC,CE
