SPECIFICATION:

Rating: 0.3A 30V DC

SIZE: 50.0(L) x 9.4(W) mm

8P4T , RG = 2 ~ 9 mm

Travel: 2 mm

Terminal Pitch: 2 mm , 4 mm

Dielectric Strength: AC 250 V 1 Minute

Insulation Resistance: 100 MΩ Mim. 250V DC

Contact Resistance: 50MΩ Max.

Operating Temperature: -25oC ~ +70oC

Life Test: 10,000 Cycles
