SPECIFICATION:

Rating: 15A 125V AC / 10A 250V AC

Vithstand Voltage: AC 1500 V 1 Minute

Insulation Resistance: 200 MΩ Mim. 500V DC

Contact Resistance: 20MΩ Max.

FUNCTION:

SPST 2PINS

PL-703: ON-OFF

PL-703A: (ON)-OFF

□=Terminal Type

H1=Screw Type (7.0mm)   H4=187" (4.8mm)

H2=Screw Type (6.8mm)   H5=250" (6.3mm)

H3=Solder Type
