SPECIFICATION:

Rating: 0.3A 30V DC

SIZE: 35.0(L) x 7.0(W) mm

6P3T , RG = 4.5 mm

Travel: 2 mm

Terminal Pitch: 2 mm,4 mm

Dielectric Strength: AC 250 V 1 Minute

Insulation Resistance: 100 MΩ Mim. 250V DC

Contact Resistance: 50MΩ Max.

Operating Temperature: -25^oC ~ +70^oC

Life Test: 10,000 Cycles

Approvals : RoHS
