SPECIFICATION:

Rating: 0.3A 30V DC

Circuit: 1P3T 4PIN

Travel: 2mm , Non Shorting

Operating Force: 200 ± 100g

Knob Length: 4.4mm

Dielectric Strength: AC 250 V 1 Minute

Insulation Resistance: 100 MΩ Mim. 250V DC

Contact Resistance: 100MΩ

Operating Temperature: -25oC ~ +70oC

Mechanical Life: 30,000 Cycles

Electrical Life: 10,000 Cycles
